STEAM HOSE

Steam Hose

232MB Steam Queen®(Specification 3602EL)

RECOMMENDED FOR: All types of steam — saturated and superheated — up to 250 PSI + 450oF (+232oC).

                         NOTE: DO NOT ALTERNATE USE BETWEEN STEAM AND WATER.

TEMPERATURE:  -40°F to +450°F (-40°C to +232°C) continuous service.

CONSTRUCTION: Tube: Type P2 (EPDM). Black.
                                  Reinforcement: Braided, high tensile steel wire.
                                  Cover: Type B1 (special compound designed to withstand heat and oil). Red. All sizes are perforated.

COUPLINGS:  [14] or [15] only. Reference pages 118-128.

PACKAGING: 50′ lengths: Coiled in a carton. 3/8″ through 3/4″: Packaged in 200′ to 300′ reels. Maximum of 3 pieces. Minimum length 25′. One length under 100′.

BRANDING:  Continuous modeled brand. Exsample:  232MB Steam Queen® 3/4 Inch 2 Wire Braid 250 PSI WP at 450 Degrees F Made In U.S.A. Caution: Tighten Clamps Before Using.”

SPECIAL ORDER REQUIREMENTS: Special production runs require minimum order quantities of 5,000 feet for sizes less than 1-1/2″ and 600 feet for 1-1/2″ and larger.

REMNANT LENGTHS:  N/A

STANDARDS:  Cover: RMA (Class C) Limited oil resistance.
